| Parameter | measuring unit | Parameter value |
| Length | mm(in.) | 625(25) |
| Width | mm(in.) | 343(13.5) |
| Height | mm(in.) | 1013(39.9) |
| Transom height | mm(in.) | 381(15.0) |
| Net Weight | kgs | 17.5 |
| Full throttle operating range | r/min | 4000~5000 |
| Maximum output | r/min | 1.9(2.5)@5500 KW(HP)@ |
| Idling speed | r/min | 2000~2200 |
| Cylinder quanitity | 1 | |
| Displacement | ml | 72 |
| Bore×Stroke | mm(in.) | 47×43(1.85×1.70) |
| Control system | Tiller | |
| Starting System | Manual | |
| Gear positions | Forward-neutral | |
| Gear ratio | 2.08(27/13) | |
| Trim and tilt system | Manual tilt | |
| Fuel tank volume | L | 0.9 |
| Engine fuel ratio | / | |
| Engine oil | L | 0.35 |
| Gear oil | ml | 75 |
| Propeller spec | in | 3-71/7"×6" |
