| Parameter | measuring unit | Parameter value |
| Length | mm(in.) | 717(28.2) |
| Width | mm(in.) | 361(14.2) |
| Height | mm(in.) | 1156(45.5) |
| Transom height | mm(in.) | 560(22.1) |
| Net Weight | kgs | 24 |
| Full throttle operating range | r/min | 4000~5000 |
| Maximum output | r/min | 3.6(5)@4500 KW(HP)@ |
| Idling speed | r/min | 1250~1350 |
| Cylinder quanitity | 1 | |
| Displacement | ml | 120 |
| Bore×Stroke | mm(in.) | 61×41(2.32×1.61) |
| Control system | Tiller | |
| Starting System | Manual | |
| Gear positions | Forward-neutral-reverse | |
| Gear ratio | 2.08(27/13) | |
| Trim and tilt system | Manual tilt | |
| Fuel tank volume | L | 1.1 |
| Engine fuel ratio | / | |
| Engine oil | L | 0.5 |
| Gear oil | ml | 100 |
| Propeller spec | in | 3-71/7"×7" |
