Volage/Power: 96V/9KW
Max. current: 120A
Volage/Power: DC96V/9KW
Motor: DC Brushless motor PMSM
Undervoltage Protection (V): 68 Overvoltage Protection (V): 120
Rotating speed: 5500r/min
Gear shift: Reverse/Forward
Cooling system: Water cooling Gear box capacity: 250ml Recommended Gear oil:Hypoid gear oil SAE #90
Propeller diameter: 9¼ * 12-J
Transom height(short/long shaft optional): 44cm/57cm
With power display
Rec.boat size: 4.2m - 7.0m G.W./N.W.: 55/51kGS
Packing Size: 122*70*39cm
Loading Qty.: 80PCS/20GP
Without battery Adaptable battery voltage range (V): 72- 108 Recommend battery: 96V/100AH The duration of 96V/100A battery is1.0H working on the 3.8m aluminum boat with loading 550KG, the max speed is 30KM/H
Recommend battery: 96V/200AH The duration of 96V/200A battery is2.0H working on the 4.2m aluminum boat with loading 1000KG, the max speed is 27KM/H
